Sample Type: Fingertip capillary whole blood or venous whole blood
Blood Volume Required:
- Blood glucose test: approximately 0.8 µL
- Uric acid test: approximately 1.5 µL
Measurement Range:
- Blood glucose: 1.1 mmol/L – 33.3 mmol/L (20 mg/dL – 600 mg/dL)
- Uric acid: 179 µmol/L – 1190 µmol/L (3.0 – 20.0 mg/dL)
Test Duration:
- Blood glucose test: 6 seconds
- Uric acid test: 11 seconds
Power Supply:
- Two AAA alkaline batteries (DC 3V, 10mA); pay attention to polarity
Analyzer Lifespan: 3 years
Operating Time:
- When fully charged, the device can operate continuously for 50 hours
- Each use lasts 5 minutes, allowing 600 uses per full charge
Temperature Adaptation Time: At an ambient temperature of 20°C:
- From minimum storage temperature (-20°C) to ready-to-use state: 1 hour
- From maximum storage temperature (55°C) to ready-to-use state: 1 hour
Manufacturing Date & Expiry Date: Refer to box label
Testing Temperature Range: 10°C – 40°C
Humidity for Testing: ≤ 80%
Product Dimensions:
- BGM-T1: 103 × 60 × 26 mm
- BGM-T2: 109 × 60 × 23 mm
Weight: Approximately 60-65 g (excluding batteries)
